Customize your Project Plan
   
by tailoring Smartsheet

(5) Then we create a new column, "Timing Status", with the data type "Symbol" (red, yellow,
green, blue).

red = Still open task, but Due Date has already passed,  ALARM
yellow = Due Date within 3 days,  pay ATTENTION
green = Due date NOT passed yet, therefore  OKAY
blue = Task accomplished,  already DONE

Then we care for the "Timing Status" and place this formula there:

=IF(Done@row = 1, "Blue", IF(Finish@row < $[Status Day]$1, "Red", IF($[Status Day]$1 - Finish@row
> -3, "Yellow", IF(Finish@row > $[Status Day]$1, "Green"))))

We don't convert this into a column formula yet, because we are later supposed to make still some
changes at some certain cells.

(6) Now we empty the cells of the parent and sub-parent rows at the column "Timing Status" (so
for row 3, row 9, and row 12 as well).

(7) To switch the column symbols back into numbers (red = 1, yellow = 2, green = 3, blue = 4),
we create a new column, called "HELPER1" (actually the name doesn't matter) and
place there this formula:

=IF([Timing Status]@row = "Blue", 4, IF([Timing Status]@row = "Green", 3, IF([Timing Status]@row =
"Yellow", 2, IF([Timing Status]@row = "Red", 1))))
